SC9 Slewing Drive Performance Parameters
We are offering precise slewing drive for solar tracking. SC19 precise slewing drive for pv,cpv.csp,hcpv solar tracking and wind power.
Optional items:12V,24V DC motor, 220V,230V,380V AC motor and encoder.
Model Number : SC9-61-RC
Supply Ability : 3000 Piece/Pieces per Month
Minimum Order Quantity : 1 Piece
Brand Name : Coresun Drive
Type : precise slewing drive for solar tracker
Warranty Time：5 years
Using Life：25 years
Material | 42CrMo, 50Mn | Output Torque | 12.2 kN.m |
Tilting Moment Torque | 33.9 kN.m | Holding Torque | 38.7 kN.m |
Static Axial Rating | 338 KN | Static Radial Rating | 135 KN |
Dynamic Axial Rating | 81 KN | Dynamic Radial Rating | 71 KN |
Gear Ratio | 61:1 | Efficiency | 40% |
OEM | Available | HS Code | 8483409000 |
Slew drives are an all-in-one unit comprised of geared slew ring, drive gear, housing, and motor (electric or hydraulic). Designed for axial, radial, and moment loading.
Coresun Drive Slew Drives are powered with hour glass (Double Enveloping) worm technology for increased load handling, efficiency and accuracy.
Coresun Drive manufactures a wide variety of drive styles, model sizes, performance ranges, sealing options, and mounting characteristics.
Standard model sizes from 75mm to 800mm in diameter.
Performance load characteristics range from:
– 6kNm to 220kNm holding torque
– 200Nm to 63kNm output torque
– 500Nm to 271kNm overturning moment load capacity
Gear reduction ratio 30:1 to 156,600:1
Horizontal, vertical, or combination of multiple axis mounting
Single or Dual drive
Electric or Hydraulic motor option
Housing: Open or Closed
Customized input configurations
Custom designs per application requirements
