SC solar tracker slew drive is the improved design on the basis of SE and SD model. It’s also called solar tracker actuator motor, solar panels rotation slew gear and solar panels tracker device.
As the core transmission component of solar tracking, the service life and stability of slew drive worm gear motor are very important. High torque output is required while ensuring tracking accuracy.
Production Description:
Model | SC12 | Brand | Coresun Drive |
Application | Solar Tracker | Type | Enclosed |
Material | 42CrMo,50Mn | Output Torque | 9360N.m |
Tilting Moment Torque | 54.3KN.m | Holding Torque | 43KN.m |
Static Axial Rating | 475KN | Static Radial Rating | 195 KN |
Dynamic Axial Rating | 159KN | Dynamic Radial Rating | 112KN |
Gear Ratio | 78:1 | Efficiency | 40% |
Coresun Drive slew drive worm gear motor is your best solution and partner
1. The slew drive can bear large axial force, radial force and tipping moment, and can drive the turntable or bracket to rotate horizontally and pitching Angle.
2. Function area
● Solar energy field: for tracking bracket structure design, drive power generation system to track the sun, improve power generation efficiency.
● Construction machinery: mainly used to drive two relatively rotating objects to rotate 360 degrees. The main advantages of slew drive
● Coresun adopts torus worm design, multi-tooth contact, bearing large output torque.
● Product performance indicators through strict type test to ensure that the product qualified.
● Specific products can be customized according to customer requirements.
● Products can be divided into: enclosed type, precision type, zero clearance, open type, heavy vehicle, bipolar transmission six series.
● Coresun production process through the ISO9001 quality system certification, products through the CE certification.
Holding Torque and Tracking Precision Testing available for all of models of slew drive worm gear slew gear.
