Coresun@ dual axis two axis slewing drive gearbox motor with 12VDC, 24VDC, 230VAC motor or customized requirement. We offer high-quality, custom-tailored slewing rings, drives and gears for your manufacturing project.
SVH3 Production Description:
Model | SVH3 | Brand | Coresun Drive |
Type | Dual Axis | IP Class | IP65 |
Material | 42CrMo,50Mn | Output Torque | 716N.m |
Tilting Moment Torque | 1KN.m | Holding Torque | 2KN.m |
Static Axial Rating | 30KN | Static Radial Rating | 15KN |
Dynamic Axial Rating | 9.6KN | Dynamic Radial Rating | 8.4KN |
Gear Ratio | 62:1 | Efficiency | 40% |
The compact worm slewing drives are characterized. Their high power density. The worm teeth ensure that the torque is transmitted to the slewing ring. As a result, this design is particularly suitable when high forces and limited installation space is available. For example in a steering gear for the chassis of crane and other heavy-duty vehicle cranes or agricultural machines
A slew drive is a ready-to-install unit consisting of a ball or roller slewing ring for the simultaneous transfer of axial and radial forces as well as tilting moments with hydraulic or electric drives in a completely enclosed housing.
Spur gear unit or worm drive
Max. torques of up to 450 kNm
Max. tilting moment load of up to 1,200 kNm
Raceway diameter of up to approx. 1,000 mm
Unlimited slewing range
Fast installation
Smooth, jolt-free movement - no stick/slip effect
Maximum safety through full encapsulation
Cost-efficient, proven technology
Compact, space-saving, heavy duty
Coresun@ slewing drive motor will be processed by Spar Salt Spray Test for ensuring the painting specification quality and protection grade.
